1 Meter TL Translucent 1.75mm Bowden Tubing

Store/Shop by Tubing/Bowden Tubing
SKU 2001
$11.99
Fittings
Please choose
1
Product Details
Brand: Capricorn
Length: 1 Meter
ID: 2.0mm
OD: 4.0mm
Experience Clearly Better Performance
Elevate your printing experience with our distinctive translucent blue PTFE tubing! Precision-engineered with a 2mm inner and 4mm outer diameter, perfectly optimized for 1.75mm filaments.
See the difference, literally. Our TL Series stands out with its unique translucent blue color that doesn't just look stunning—it lets you visually monitor filament movement in real-time.
  • Superior Manufacturing Standards
  • Enhanced visibility for quick troubleshooting and flow monitoring
  • Unmatched Precision
  • Perfectly round profile throughout the entire length
  • Crafted from pure virgin PTFE—no recycled materials
  • Precise diameter tolerance for reliable filament control
Perfect Balance of Quality and Convenience
While our XS Series offers tight inner diameter for extreme performance, the TL Series delivers exceptional quality for everyday printing needs with its more forgiving 2mm inner diameter, that wont choke on oversized or inconsistent filaments, with the added benefit of translucency for visual feedback.
Each 1-meter length comes with a Capricorn sticker to proudly display on your printer—because when you've upgraded to the best, why not show it?
Upgrade to visible reliability that performs as good as it looks!

Data Sheet

Our Premium TL Series Light Blue Tubing
Additives Blue Color
Best For Chunky Filaments YES
Best For Flexible Filaments NO
Can See Through YES
Pulling Friction♠ 0.8
Color Blue, Translucent
Density (kg/m3) 2100 +/-100
Hardness 55
Inner Diameter (mm) 2.05 +/- 0.05
Linear Thermal Expansion at 250 °C 3.4-3.6%
Material Highest Quality Pure Virgin PTFE
Melting Point (°C)♥ around 300
Outer Diameter 3.95 +/- 0.05
Roundness (ϵ) < 0.1
Stiffness§ Medium
Thermal Conductivity (W/m-k) 0.25
Wear Rate (gm/s) 0.01
Young's Modulus (GPa)¥ 0.5


♠Pulling Friction is calculated as the average force required to pull 1.2 meters of 1.75mm PLA filament through 1 meter of tubing at a constant speed, relative to 1 meter of cheap white reference tubing. Note that although we observed the friction of the TL series to be about the same or even slightly lower than our XS series, it also has a larger internal diameter.
§Other Bowden tubes may vary significantly in stiffness, depending on the material from which they're made. Our tubing generally tends to be more flexible than most, with the TL being more flexible than XS.
¥Young's Modulus (YM) is the measure of elasticity of the material. Our XS Series additives give the PTFE a slightly greater YM than the TL Series.
♥Temperatures were approximated by heating samples of all tubing simultaneously, observing how quickly each one began to deform. Printer failures may happen at significantly lower temperatures.
Printing high temperature materials may create dangerous off-gassing. Please refer to the Safety Page.





* Data Current as of 11/11/17 Detailed Specs
